Printing Grade Clear Polycarbonate Film Sheet

THPC811 is Polish finish one side, Polish finish second side printing grade clear polycarbonate film Product Features： 1.Good printing performance, 2.Low water absorption, 3.High temperature resistance and flame retardant performance, 4.Good dimensional stability and creep resistance, impact...

Send Inquiry

THPC811 is Polish finish one side, Polish finish second side printing grade clear polycarbonate film

Product Features：

1.Good printing performance,

2.Low water absorption,

3.High temperature resistance and flame retardant performance,

4.Good dimensional stability and creep resistance, impact resistance and folding performance.

Applications：

-Overlays Graphics

-High-performance labels

-Signs and Advertising

-In-mould decorations

Widely used in computers, membrane switches, wide-angle lenses, electronic panels, mobile phone cases, luggage, signs, sports helmets, plastic, advertising light boxes, etc.

PC头盔_副本

Code

Color

Texture

Thickness（mm）

Width（mm）

THPC811

Natural

Polished / Polished

0.100 ~ 4.000 ( 0.004” ~ 0.157” )

915 & 1220 ( 3’& 4’ )

Thickness Tolerances

d<0.5mm ±10um

0.5≤d<1.2mm ±15um

d≥1.2mm ±25um

Parameters of the Printing Grade Clear Polycarbonate Film Sheet

Item	Test Methods	Units	Value
PHYSICAL
Specific Gravity	ASTM D792	g/cm³	1.2
Transmittance	ASTM D1003	%	≥89
Water Absorption Equilibrium, 24 HRS	ASTM D570	%	0.35
MECHANICAL
Tensile Strength	ASTM D882	Mpa	≥60
Elongation Ultimate	ASTM D882	%	≥90
THERMAL
Vicat Softening Temperature	ASTM D1525	℃	135
Thermal Shrinkage @135℃	ASTM D1204	%	≤1
ELECTRICAL
Dielectric Strength @10mils	ASTM D149	KV/mm	≥30
Volume Resistivity @25℃, 50%RH	ASTM D257	Ω·cm	>1x1017
Surface Resistivity @25℃, 50%RH	ASTM D257	Ω	>1x1015
FLAMMABILITY
UL Flamability @≧20mils	UL 94	--	V-2
